XPON ONT P4（1GE+CATV）
P4 supports maximum data rates of up to 2.488Gbps downstream and 1.244Gbps upstream. Along with a 10/100/1000Mbps ...
XPON ONT P4（1GE+CATV）
|
General |
|
|
Protocol Standards |
ITU-T G.984.x and IEEE802.3ah |
|
Distance |
20Km Max |
|
Data Rates |
GPON:Upstream rate 1.244Gbps Downstream rate 2.488Gbps EPON:Upstream rate 1.25Gbps Downstream rate 1.25Gbps |
|
PON TX Power |
1~5dBm（1310nm） |
|
PON RX sensitivity |
<-28dBm（1490nm） |
|
Power |
≤ 4W |
|
CATV |
|
|
Optical Receive |
-15～+2 dBm |
|
AGC range |
-12～-2 dBm |
|
Fiber return loss |
>14 dB |
|
wave length |
1100～1600 nm |
|
Connector |
RF |
|
C/N |
≥ 45 dB |
|
C/CTB |
≥ 62 dB |
|
C/CSO |
≥ 61 dB |
|
BW |
40~ 1000 MHz |
|
Output level |
≤82dBμV |
|
Hardware |
|
|
Interfaces |
1xSC/UPC or 1xSC/APC (optional) 1x 10/100/1000Mbps LAN port 1x RF port |
|
Buttons |
Reset Button |
|
Power Supply |
DC 12V 0.5A |
|
Dimensions (W x D x H) |
104*73*22mm(length*width*height) |
|
Environment |
|
|
Operating Temperature |
-10°C~50°C |
|
Storage Temperature |
-40°C~70°C |
|
Operating Humidity |
10%~90%, non-condensing |
|
Storage Humidity |
5%~95% non-condensing |
|
Certifications |
CE, RoHS |
|
Software |
|
|
WAN Type |
Dynamic IP/Static IP/PPPoE |
|
DHCP |
Server, Client, DHCP Client List, Address Reservation |
|
Quality of Service |
Bandwidth Control |
|
VLAN |
Port-based VLAN GVRP IEEE802.1Q VLAN |
|
Access Control |
Local Management Control, Host List, Access Schedule, Rule Management |
|
Route |
Support NAT Support PPPOE Support Server Client Support Route |
|
PON Mode |
GPON Mode |
|
Management |
Access Control Local Management Remote Management |
|
Internet Protocol |
IPv4, IPv6 |
|
Package Contents |
|
|
Package Contents |
1 x GPON ONT 1 x Quick Installation Guide 1 x Power Adapter |
